Swivel Loading Ramps

"Light Plus Series" by WM System

The WM Systems Light Plus series loading ramp is our most popular ramp system, favored by large fleets and owner-operators across North America because of its industry-leading swivel function. This standard feature allows for 90 degree external swivel, acting as a second door to allow for cargo area access without the need to deploy the ramp. Customers love the swivel function not only for easy cargo access, but also for the ability to load 40x48 pallets into the cargo area using a forklift. An optional internal swivel kit can be installed at any time, allowing the ramp to lock near the wheel well for out-of-the-way storage.

Additionally, this ramp comes equipped with a robust spring assist system making deployment or storage easy for vehicle operators of wide-ranging physical abilities.

Constructed of high quality materials, nearly every piece of this ramp is constructed of aluminum for longevity in rainy, snowy, icy, muddy and saltwater/coastal climates.

The Light Plus series loading ramp is suitable for full size vans, box on body, and full size box trucks.

Brand: WM System
Product line: Light Plus Series loading ramps
Country of origin: Italy

Multiple width and length options are available.

Widths from 31" - 47", lengths from 78" - 128". Custom sizes can be special ordered.

Left-hand swivel is standard on Light Plus series ramps, shown on a Mercedes Sprinter (9ALPC279 Perforated ramp).

Standard left-hand swivel pivots the ramp on the driver's side, allowing easy cargo area access.

Internal lock kit and position shown for a Light Series loading ramp.

Optional: Internal lock kit available to store the ramp against the wheel well.

Standard weight capacity is ideal for light and medium everyday loads. Shown is a four wheeler being loaded on a Light Plus series ramp, showcasing 1,500 lb. capacity.

1,500 lb. standard capacity.

Ramp being used as a plank to a high curb, with side door install application

Use ramp as a plank on steps, van-to-van, loading docks and more while maintaining weight capacity.

Optional third-piece section extends the length.

Optional: Third piece extensions available for even greater length.

Spring assist close-up on Light Plus series ramp.

Spring assist standard on every ramp for ease of use and long-term reliability.

Flexible transition threshold hinges on the ramp to adjust to the needed transition height.

Each ramp comes with a flexible flap threshold that provides a smooth transition from ramp to vehicle.

No drilling is required with our no-drill mounting kit.

New no-drill mounting hardware available for certain van models. Inquire today!

Most users can deploy and stow the ramo using only one hand.

Ramp requires only 22 lb. of force to deploy and store.

Wheels at the end of the ramp close-up on Light series loading ramp

Equipped with wheels at the end of ramp to make deployment easy.

Aluminum ramp surface available in solid or perforated texture.

Light series ramp right-hand swivel option shown on a Ford Transit van

Optional: Right-hand swivel can be special ordered, ideal when a rear AC unit is installed.

View application guide by vehicle make:

Ford Cargo Van
Fit Guide

RAM Cargo Van
Fit Guide

View swivel ramps fit guide for Mercedes

Mercedes Cargo Van Fit Guide

Nissan Cargo Van Fit Guide

Application Guide for All Vehicles

Model	Transit High Roof	Transit Mid Roof	Transit Low Roof	ProMaster Super High Roof	ProMaster High Roof	ProMaster Low Roof	Sprinter High Roof	Sprinter Low Roof	NV High Roof	NV Low Roof
9ALPC001	✔	✔	✔	✔	✔	✔	✔	✔
9ALPC235	✔	✔		✔	✔		✔		✔
9ALPC235/RH	✔	✔		✔	✔		✔		✔
9ALPC229	✔			✔	✔		✔		✔
9ALPC551	✔	✔	✔	✔	✔	✔	✔	✔
9ALPC551/3S	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔
9ALPC553	✔	✔		✔	✔	✔	✔	✔	✔	✔
9ALPC553/3S	✔	✔		✔	✔	✔	✔	✔	✔	✔
9ALPC275	✔	✔		✔	✔		✔		✔
9ALPC279	✔			✔	✔		✔		✔
9ALPC235/PERF	✔	✔		✔	✔		✔		✔
9ALPC235/PERF/RH	✔	✔		✔	✔		✔		✔
9ALPC229/PERF	✔			✔	✔		✔		✔
9ALPC553/PERF	✔	✔		✔	✔	✔	✔	✔	✔	✔
9ALPC275/PERF	✔	✔		✔	✔		✔		✔
9ALPC279/PERF	✔			✔	✔		✔		✔

If you have a factory-supplied rear AC unit (blower) installed in your Ford Transit, only a right-hand swivel ramp will be compatible with your vehicle. If the blower is covered with a plastic shroud, a simple modification may be required to allow for clearance of mounting hardware. Please call for more details.

Model	Description	Stored height (in)	W (in)	L (in)	Capacity (lbs)
9ALPC001	Light Plus Series Ramp, Standard capacity, Solid surface, LH swivel, 2 section	46	31	79	1500
9ALPC235	Light Plus Series Ramp, Standard capacity, Solid surface, LH swivel, 2 section	61	37	108	1500
9ALPC235/RH	Light Plus Series Ramp, Standard capacity, Solid surface, RH swivel, 2 section, Rear AC unit compatible	61	37	108	1500
9ALPC229	Light Plus Series Ramp, Standard capacity, Solid surface, LH swivel, 2 section	68	37	126	1500
9ALPC551	Light Plus Series Ramp, Standard capacity, Solid surface, LH swivel, 2 section	46	47	78	1500
9ALPC551/3S	Light Plus Series Ramp, Low capacity, Solid surface, LH swivel, 3 section	46	45	116	1500
9ALPC553	Light Plus Series Ramp, Standard capacity, Solid surface, LH swivel, 2 section	56	47	98	1500
9ALPC553/3S	Light Plus Series Ramp, Low capacity, Solid surface, LH swivel, 3 section	56	45	135	1500
9ALPC275	Light Plus Series Ramp, Standard capacity, Solid surface, LH swivel, 2 section	61	47	108	1500
9ALPC279	Light Plus Series Ramp, Standard capacity, Solid surface, LH swivel, 2 section	69	47	126	1500
9ALPC235/PERF	Light Plus Series Ramp, Standard capacity, Perforated surface, LH swivel, 2 section	61	37	108	1500
9ALPC235/PERF/RH	Light Plus Series Ramp, Standard capacity, Perforated surface, RH swivel, 2 section, Rear AC unit compatible	61	37	108	1500
9ALPC229/PERF	Light Plus Series Ramp, Standard capacity, Perforated surface, LH swivel, 2 section	68	37	126	1500
9ALPC553/PERF	Light Plus Series Ramp, Standard capacity, Perforated surface, LH swivel, 2 section	56	47	98	1500
9ALPC275/PERF	Light Plus Series Ramp, Standard capacity, Perforated surface, LH swivel, 2 section	61	47	108	1500
9ALPC279/PERF	Light Plus Series Ramp, Standard capacity, Perforated surface, LH swivel, 2 section	69	47	126	1500
